Capsules machine pressing product export adjustment

Capsules machine pressing product export adjustment

The total length of the capsule after pressing must be adjusted according to the requirements of different specifications and different lengths of the capsule, or when replacing the capsule. The gap between the pressing baffle and the very high point of the capsule in the module should be 0.2-0.3mm (measured with a feeler ruler), which is adjusted by the thickness of the replacement washer. The adjustment method of the height of the push rod is to put the closed capsule into the module, adjust the length of the CAM connecting rod to adjust the length of the screw, so that the push rod movement to a high position, the column pin against the lower part of the capsule shall prevail. In the filling process, if it is found that the capsule is not closed properly, such as too long at the end of the lock closure, too short capsule deformation. Careful readjustment is needed at this point. Tighten nut after setting.

There is a gap between the finished product seeker and the finished product capsule to prevent the capsule from being damaged, and the finished product capsule can be successfully exported. As long as the locking screw is loosened, the seeker can be adjusted by moving, and the nut can be tightened after setting. The position of the push rod is adjusted by adjusting the positioning of the screw rod, so that the push rod moves very high to push out the capsule, and the low position does not touch the module.
