Lubrication and maintenance of tablet press

Views: 0     Author: Site Editor     Publish Time: 2021-02-26      Origin: Site

Lubrication and maintenance of tablet press

(1) all moving parts on the surface of the friction lubrication is to ensure that the machine run properly and prolong the service life of the important link, especially if the main moving parts under the condition of lack of oil dry transit transfer quickly damage and cannot be used, so the tablet machine before use must be full cup of oil, oil hole, and the friction surface and lubricating oil, and empty operation make the friction surface is full of oil film, and then can be put into use. From now on each shift refueling on time, but each refueling should not be too much, so as not to spill affect cleaning, stained tablets.

(2) Each shift must check whether the screws are loose, in the process of work should also pay attention to check, if there is loose tighten immediately, so as to avoid failure. The main parts are: the upper punch fastening nut, the middle die fixing screw, the lower punch fixing screw; Connecting rod locking nut, connecting rod pin setting screw; Lifting fork lock nut (2 pieces) butterfly screws; Fixed screws for middle die table (2 pieces).
