Maintenance of single stamping machine

Views: 3     Author: Site Editor     Publish Time: 2021-03-10      Origin: Site

Maintenance of single stamping machine

1, all moving parts on the surface of the friction lubrication is to ensure that the machine run properly and prolong the service life of the important link, especially if the main moving parts under the condition of lack of oil dry transit transfer quickly damage and cannot be used, so the tablet machine before use must be full cup of oil, oil hole, and the friction surface and lubricating oil, and empty operation make the friction surface is full of oil film, and then can be put into use. From now on, each shift refueling on time, but each refueling should not be too much, so as not to spill the influence of cleaning, stained tablets.

2, before each shift must check whether the screws are loose, in the process of work should also pay attention to check, if there is loose tighten immediately, so as to avoid failure. The main parts are: the upper punch fastening nut, the middle die fixing screw, the lower punch fixing screw; Connecting rod locking nut, connecting rod pin setting screw; Lift fork lock nut (2) butterfly screws; Set screws for middle die table (2 pieces).

3. Before each shift and after each shift shift, it is necessary to manually test several tablets, and then open the electric tablet after there is no problem.

4. In the process of tablet pressing, the quality of the punching die must be checked frequently. If there is a lack of edge, crack or serious damage, it should be replaced in time to avoid failure and damage to the machine and affect the quality of the tablet.

5, every day after use should be the remaining powder out, wipe the machine parts. If it is out of service for a long time, the die shall be removed and the friction surfaces of the machine shall be removed. The working face is cleaned, coated with anti-rust oil and covered with dustproof clothing. The die should be cleaned and preserved in oil.

6. Check the parts regularly, twice a month.
