Performance test of tablet press

Views:0     Author:Site Editor     Publish Time: 2021-01-30      Origin:Site

Performance test of tablet press

Test 1: check whether the connection of electrical and vacuum dust removal meets the requirements, and the lubrication of each part must meet the requirements.

Check the die according to the die quality standard and install the die according to the instruction.

Turn the hand wheel to rotate the table 2-3 times to make sure that the middle die and the regulating wheel can slide flexibly without collision and hard rubbing.

Safety protection device, hopper installation meets the requirements, emergency brake system should be sensitive and reliable.

Check the motor steering, do not reverse, and confirm that installation validation has been performed and approved.

Test 2: No load operation for 60 minutes, noise no more than 82dB (A).

All connectors and fasteners are connected reliably without loosening.

Smooth operation, no abnormal vibration and impact sound.

Clutch and gearwheel adjust flexibly and reliably, and position correctly.

All parts are well lubricated.

The powder sucker has enough suction.

Air and load currents meet the requirements.
