What are the performance of the tablet press in good condition?

Views:0     Author:Site Editor     Publish Time: 2020-12-19      Origin:Site

What are the performance of the tablet press in good condition?

1. Each lubrication point can produce oil under manual and automatic state.

2. Plate weight adjustment hand wheel, hardness hand wheel, pre-pressing hand wheel rotation is flexible and reliable.

3. The dustproof rings of the upper and lower punching plates shall be sealed without damage:

4. The upper and lower main pressing wheel and the upper and lower prepressing wheel rotate flexibly.

5. The middle die should be flush with or slightly lower than the punching plate and be fastened.

6. The working face of upper guide rail plate is smooth without burr sag.

7. The top punch can rotate in the die hole. Insert the die accurately at preloading without colliding.

8. The damping force received by the punch in the die hole is uniform and consistent.

9. The platform is parallel to and above the rotary table.

10. The scraper is tightly connected with the turntable, and the return powder ring has a movement of 1-2 mm at the outlet.

11. Proper clearance between outlet guide and turntable.

12. No friction between the discharging mechanism and the rotary table.

13. There is no jamming or abnormal noise in the manual turning car.
